Tractor

Model			XA 904	XA 1004	XA 1204
Dimension (LWH)		mm	460022002950	460022002950	460022002950
Min. operating weight		kg	4220	4220	4220
Wheelbase		mm	2240	2240	2240
Wheel track (front/rear)		mm	1440-1740/1610-2210	1440-1740/1610-2210	1440-1740/1610-2210
Engine	Model	/	YTO90HP four-cylinder National II	YTO100HP four-cylinder National II	YTO120HP six-cylinder National II
	Type	/	Vertical, water-cooling, four stroke, common rail Vertical, water-cooling, four stroke, common rail	Vertical, water-cooling, four stroke, common rail Vertical, water-cooling, four stroke, common rail	Vertical, water-cooling, four stroke, common rail Vertical, water-cooling, four stroke, common rail
	Number of Cylinders Qty of cylinders	cylinder	6	6	6
	Rated power	HP/KW	90HP/66.17KW	100HP/73.53KW	120HP/88.3KW
	Rated speed	r/min	2200	2200	2200
Drive train Drive train	Clutch	/	Single disc, dry, independent control, dual stage	Single disc, dry, independent control, dual stage	Single disc, dry, independent control, dual stage
	Gearbox	/	TDF16+8	TDF16+8	TDF16+8
	Gear shift type	/	shift sleeve	shift sleeve	shift sleeve
Steering	Steering type	/	Full hydraulic steering	Full hydraulic steering	Full hydraulic steering
Brake	Brake type	/	Mechanical control, wet, disc	Mechanical control, wet, disc	Mechanical control, wet, disc
Walking device	Tire size (front/rear)	/	12.4-24/16.9-34	12.4-24/16.9-34	12.4-24/16.9-34
Working device Working device	Suspension device type Suspension device type	/	Rear, three-point suspension	Rear, three-point suspension	Rear, three-point suspension
	Suspension device category	/	Category II	Category II	Category II
	Tillage Depth Adjustment	/	Height adjustment, floating control	Height adjustment, floating control	Height adjustment, floating control
	Hydraulic output device	group	2	2	2
	Standard PTO speed	r/min	6键540/1000	6键540/1000	6键540/1000
Other	rops/cab		rops	rops	rops
Standard configuration:			YTO90HP four-cylinder engine, 12-inch independent dual-action clutch, clutch mechanical assist, TDF16+8 high and low gears (helical gear), thickened half pipe, steplessly adjustable rear wheels, flat floor and safety frame, 12.4-24/16.9-34 tires, two sets of hydraulic outputs, dual high-pressure lifters, suspension components, 10 pieces of 40 kg front weights/piece, one layer of 160 kg rear weights	YTO100HP four-cylinder engine, 12-inch independent dual-action clutch, clutch mechanical assist, TDF16+8 high and low gears (helical gear), thickened half pipe, steplessly adjustable rear wheels, flat floor and safety frame, 12.4-24/16.9-34 tires, two sets of hydraulic outputs, dual high-pressure lifters, suspension components, 10 pieces of 40 kg front weights/piece, one layer of 160 kg rear weights	YTO120HP six-cylinder engine, 12-inch independent dual-action clutch, clutch mechanical assist, TDF16+8 high and low gears (helical gear), thickened half pipe, steplessly adjustable rear wheels, flat floor and safety frame, 12.4-24/16.9-34 tires, two sets of hydraulic outputs, dual high-pressure lifters, suspension components, 10 pieces of 40 kg front weights/piece, one layer of 160 kg rear weights
Other optional: Available			Swinging hitch +¥1000(CNY)	Swinging hitch +¥1000(CNY)	Swinging hitch +¥1000(CNY)
			Quick hitch +¥800(CNY)	Quick hitch +¥800(CNY)	Quick hitch +¥800(CNY)
			Air brake system (including air pump) +¥2000(CNY)	Air brake system (including air pump) +¥2000(CNY)	Air brake system (including air pump) +¥2000(CNY)
			Luxury air-conditioned cab +¥7200(CNY)	Luxury air-conditioned cab +¥7200(CNY)	Luxury air-conditioned cab +¥7200(CNY)
			Change 14.9-26/18.4-38 +¥6000(CNY)	Change 14.9-26/18.4-38 +¥6000(CNY)	Change 14.9-26/18.4-38 +¥6000(CNY)
			Add front mudguards +2500(CNY)	Add front mudguards +2500(CNY)	Add front mudguards +2500(CNY)
			Pneumatic suspension seat +1200(CNY)	Pneumatic suspension seat +1600(CNY)	Pneumatic suspension seat +1600(CNY)
			Tire replacement with radial tires (front 360/70R28, rear 620/75R30) +10600 (CNY)	Tire replacement with radial tires (front 360/70R28, rear 620/75R30) +10600 (CNY)	Tire replacement with radial tires (front 360/70R28, rear 620/75R30) +10600 (CNY)
			LUK clutch +2000	LUK clutch +2000	LUK clutch +2000
